Cooling method: TEFC – Totally enclosed fan cooled
Degree of Protection: IP66
Output: 0,12 up to 500kW
Number of Poles: 2, 4, 6 and 8
Frames: 63 up to 355A/B
Mounting: B3R
Flexibility on mounting configuration for frames 225S/M to 355A/B: motor can have its T-box mounting converted from lateral to top mounted
Voltages: 220-240/380-415V / 380-415/660V
Class “H” insulation (ΔT = 80K)
Continuous duty: S1
Design N
Thermal protection: Alarm thermistors 1 per phase for frames for frames 160M to 200L and Alarm and Tripping thermistors 2 per phase for frame 225S/M and above
Ambient temperature: 40 °C, at 1000 m.a.s.l
Squirel cage rotor / Aluminum Die Cast
Double lip oil seal for frames 63 to 200L and Wseal sealing for frame 225S/M and above
Fan covers: steel made for frames 63 to 132M/L and cast iron made for frames 160M and above
Regreasing nipple for frames 225S/M to 355A/B
Enclosed plastic drain plug for frames 63 to 132M/L and rubber drain plug for frame 160M and above
